We also need to consider the Tacoma and 4Runner.
Prado 250 UAE 29 gallon petrol main... now you're talking! is the UAE petrol spare in the same location? that tank could be money
There is someone from the UAE on here who posted some photos of their skid plates. I asked them if they could post some photos of the full underside. Next time they have it on a lift.
Not sure if that helps our cause. I believe they’re 18 and 19 gallons respectively.
I wonder if this would fit? (Not yet out)
TOYOTA LANDCRUISER PRADO 250 SERIES BROWN DAVIS LONG RANGE FUEL TANK – Brown Davis- Long Range Fuel Tanks, Underbody Protection, Roll Cages and Motorsport
It mentions it is the same as the existing 300 series 87 litre sub tanks but for the 250's location for the Add Blue (DEF) tank. As the 250 Hybrid lacks the Add Blue tank, should it fit?
TOYOTA LANDCRUISER 300 SERIES 87LT REPLACEMENT LONG RANGE FUEL TANK – Brown Davis- Long Range Fuel Tanks, Underbody Protection, Roll Cages and Motorsport
The existing 300 series 87 litre sub tanks is available now for a mere $1,155 (before tax and shipping of course.
Toyota Landcruiser 300 Series - 87L STEEL AUXILIARY Brown Davis Fuel T
51.8% INCREASE IN FUEL CAPACITY! COMPATIBLE MODELS - 2022- GX, GXL, VX, SAHARA, GR SPORT
I don't know how realistic it is to add a sub tank to the NA spec Hybrid 250 though. I think you would need to reroute the exhaust, purchase the 2nd filler neck, maybe a transfer pump. It's a a lot. But 17.9 +22.9 Gallons would be monster range. Really would help in remote camping situations being able to better utilize the vehicle as a generator.
- Moderator
- #108
One would have thought the GX tank would be a direct swap as they share the same frame, however it's the suspension that got in the way.......LOL
I do know the diesel's muffler is a different size and the fuel pump mount/securing ring might be different as well. The diesel tank probably isn't plumbed, EVAP wise, the same as the gasoline tank.
I do know the diesel's muffler is a different size and the fuel pump mount/securing ring might be different as well. The diesel tank probably isn't plumbed, EVAP wise, the same as the gasoline tank.
Can't argue with any of that. Exhaust re-rerouting is easy enough, but the rest.....tough and probably warranty voiding.
I saw you were looking for part # for the UK 2.8Diesel
Might be worth trying to get part #s for the UAE/Dubai spec Hybrid 110 Liter (29 gallon) gas/ petrol tank set up. I can't figure out if its' just one main tank as some claim or others claiming its an 80 liter main (21 Gallons like GX) + 30 liter (8 gallon) sub tank.
Others are saying just 8 gallons isn't worth messing with. However, an extra 8 gallons is a 45% increase to our 17.9 Gallons. I think that's meaningful.
UAE model is not hybrid. FWIW here are some links:
Buy the New Toyota Land Cruiser Prado 2.4L 2024 | Toyota UAE
Discover the 2024 Toyota Land Cruiser Prado, a versatile SUV built for both city & off-road driving. Explore its features & performance. Buy yours today in the UAE.
I believe both a hybrid and non hybrid version of the 2.4 L turbo 4 cylinder petrol and the 2.8L diesel are available in UAE.UAE model is not hybrid. FWIW here are some links:
Buy the New Toyota Land Cruiser Prado 2.4L 2024 | Toyota UAE
Discover the 2024 Toyota Land Cruiser Prado, a versatile SUV built for both city & off-road driving. Explore its features & performance. Buy yours today in the UAE.www.toyota.ae
I was wondering if it is structural to keep tank from deforming, definitely there for some reason
Possibly to create a baffle and reduce sloshing, but there’s that big round void on the top too. I strongly suspect they are just there to reduce the internal volume and therefore capacity of the tank by reducing weight of the tank when full.
- Moderator
- #114
I don't believe it's structural as both tanks are two pieces made from 1/8" to 1/4" plastic and thermo-welded together. There appears to be one void that is molded into both tanks and that looks to be structural to prevent the top of the tank from sagging.
IMO They started with one or the other tank and designed it to fit correctly in that vehicle. Then when they put it in the opposite vehicle........... "hey this won't fit due to the link mount" or "hey there a lot of room back near the axle, we should make it bigger"
Does it look like it could have been made 15-20% more capacity and still maintained adequate clearances? That’s my guess.
- Moderator
- #116
Oh for sure, if they would have put the LC lower together with the GX upper...... life would be great!
